USB A connector to a TC2030 6-pin Plug-of-Nails™ “With Legs” connector. It brings the USB signals directly to your PCB.
This cable has a USB A connector and USB 2.0 cable wired to a TC2030 6-pin Plug-of-Nails™ connector. It brings the USB signals directly to your PCB.
The TC2030 connector is wired as follows:
- white / D-
- green / D+
Other Tag-Connect cables with USB:
See also TC2050-PGUSB which has a 10-pin TC2050 connector with both a USB 2.0 cable and a 6-pin 0.1″ ribbon connector for JTAG.
See also TC2030-FTDI which is a USB to TC2030 cable with inbuilt FTDI 232 USB to serial convertor.
