Introducing the New Standard in Cables for In-Circuit Programming... In-Circuit Programming Cables that Save Cost and Space on Every Board!
The Benefits of Tag Connect
ZERO Cost per Board!
No mating connector required on PCB!
Tiny footprint!
High Reliability Pogo Spring Pins for Secure Connection!
Rugged Design for Highly Repetitive Use!
Designed so it can only be inserted the correct way round!
Two versions both designed to cut your costs, save you time, and save space on your PCBs!
Web Site Problems May 10th and May 11th.
Apologies that our website was unavailable from roughly 6PM Thursday to 8AM Friday (California time). This was due to unexpected problems during routine maintenance.We will probably go offline for a few hours this weekend. Thanks for your patience. If you experience problems placing an order or need data please email support@Tag-Connect.com or call +1 877 244 4156.
What's going on at Tag-Connect? New products in the pipeline!
As well as our newly available TC2030-CTX cables for ARM Cortex applications we have some other new products in the pipeline!
The upcoming 14-pin Tag-Connector family will extend our range to cover even more MCU's and DSP's.
We're also working on some very exciting active cables... think fast now! No Header - No Brainer!
There's a few other surprises up our sleeves too - watch this space!
New Product! TC2030-CTX-NL 6-Pin "No Legs" Cable with 10-pin micro-connector for Cortex processors
 with ULINK2_0_tn.jpg)
Now Availlable! 6-Pin "No Legs" TC2030 Plug-of-NailsTM Cable for use with ARM Cortex processors.
This special cable has a 6-pin TC2030-NL Tag-Connector and a 10-pin ribbon connector that mates with the FTSH-105 style micro-headers used for Cortex Debug as found in debuggers such as Keil's ULINK-2.
The footprint for the TC2030-CTX-NL Plug-of-Nailstm Connector saves over 66% of the PCB space used by typical FTSH-105 style micro-headers!
Datasheet: http://www.tag-connect.com/Materials/TC2030-CTX.pdf
Please refer to the TC2030-IDC-NL Datasheet for details of the TC2030-NL footprint
See also the TC2030-CTL "Legged" version of the cable.
For traditional ARM JTAG solutions using the 20-pin header as found on Segger's J-LINK see our TC2050-ARM2010 adapter used with TC2050-IDC (-NL) cables.
Keil's ULINK2 debugger and Tag-Connect Demo PCB and additional Legged Cable are shown for illustrative use only - not included with the cable!
New!! TC2030-CTX 6-Pin Cable for ARM Cortex
 with ULINK2_tn.jpg)
Now Available! 6-Pin Legged TC2030 Plug-of-NailsTM Cable for use with ARM Cortex processors.
This special cable has a 6-pin TC2030 Tag-Connector and a 10-pin ribbon and ribbon connector that mates with the FTSH-105 style micro-headers used for Cortex Debug Connector as found in debuggers such as Keil's ULINK-2.
Datasheet: http://www.tag-connect.com/Materials/TC2030-CTX.pdf
See also the TC2030-CTL-NL "No Legs" version of the cable with footprint that saves over 66% of the board space needed by typical FTSH-105 micro headers!
For traditional ARM solutions using the 20-pin header as found on Segger's J-LINK see our TC2050-ARM2010 adapter used with TC2050-IDC (-NL) cables.
Keil's ULINK2 debugger and Tag-Connect Demo PCB for illustrative use - not included with the cable!
Visit Tag-Connect at Design West in San Jose, March 27-29
Come see us at Design West, Booth 827. Design West incorporates what used to be known as ESC.We'll have our latest products on display including our new TC2030-CTX cable which allows Cortex SWD debugging and programming with a tiny 0.02 sq inch footprint.
Tag-Connect at Embedded World Feb 28-March 1st
We'd love to see you at booth 4-115 at Embedded World, Nuremberg Feb 28,29 and March 1st. See our latest new additions to the Plug-of-NailsTM product range.
TC-Renesas Adapter for Renesas E1 and E8a Debuggers
_tn.jpg)
The TC-Renesas Adapter allows TC2030-IDC or TC2050-IDC Plug-of-NailsTM Cables to be used with Renesas E1 or E8a Debuggers. The adapter can be used with all Renesas MCU's compatible with E1 or E8a.
Purchase from our distributors
Visit Tag-Connect at ESC Boston....
Come say "Hi" to us at the Embedded Systems Conference in Boston next Tuesday and Wednesday (27th and 28th September 2011). We'll be in booth 320 right next to the Tech Tote booth, and just a couple of booths away from ARM.Check out our full range of Plug-of-Nails(tm) Cables, adapters and demo boards including our new adapter that works with all Renesas MCU's that are compatible with E8a or E1 debuggers.Tag-Connect, No Header - No Brainer!!
