ARM20-CTX-M 20-Pin Male to TC2030-IDC Adapter for Cortex


Adapter board to use TC2030-IDC Plug-of-Nails™ cables with ARM SWD (Single Wire Debug) applications.


SKU: ARM20-CTX-M Categories: ,


The Tag-Connect ARM20-CTX-M adapter board allows our TC2030-IDC cables to be used for ARM SWD (Serial Wire Debug) applications where the existing debugger/programmer ribbon cable with 20-pin 0.1″ female IDC connectors can’t be removed and has to be extended instead.

Note: This is necessary for use with Lauterbach programmers/debugger. If your device has a 20-pin 0.1″ male connector (e.g. Segger JLink) then use the standard ARM20-CTX adapter instead.

Although intended for use with our patented TC2030-IDC (and TC2030-IDC-NL) Plug-of-Nails™ Cables, the adapter may also be useful to people wishing to use 6-pin 0.1″ ribbon headers on their PCB instead of the traditional 20-Pin header.

Note: Adapter only supplied. The TC2030-IDC or TC2030-IDC-NL cable is purchased separately.

Datasheet (For reference only – shows standard ARM20-CTX adapter)
