TC2030-CTX-STDC14 for use with STM32 processors with STLINK-V3/STLINK-V3MINI
$43.00
6-Pin Legged TC2030 Plug-of-Nails™ Cable for use with STM32 processors with STLINK-V3.
AVAILABLE
Description
6-Pin Legged TC2030 Plug-of-Nails™ programming cable for use with STM32 processors with STLINK-V3 and STLINK-V3MINI.
Note: This STDC14 cable was previously known as TC2030-CTX-ST14.
This special cable has a 6-pin TC2030 Tag-Connector and a 14-pin ribbon connector that mates with the STDC14 (FTSH-107) style micro-header found on the STLINK-V3 and STLINK-V3MINI providing the signals necessary for the SWD protocol on the STM32 MCU including SWO.
See also the TC2030-CTX-NL-STDC14 “No Legs” version of the cable with footprint that saves over 66% of the board space needed by typical FTSH-107 style micro headers!
If you need all 14-pins connected to your target board see instead the TC2070-IDC-050 cable.
For traditional ARM JTAG solutions using the 20-pin 0.1″ header as found on ST-LINK/V2 or the add-on Mezanine board in STLINK-V3SET see here.
Datasheet for similar product
This product is used in the following debugger/device solutions:
This product is used as part of the following solutions for particular debuggers, protocols and devices. Solutions may involve additional cables, adapters or retaining clips, as well as this product you are viewing now. Click on the solution links to see full solutions and installation instructions where applicable.
STLINK-V3SET for ST STM32 using SWD (via. ST-14)
STLINK-V3 for ST STM32 using SWD (via. ST-14)
STLINK-V3MINI for ST STM32 using SWD (via. ST-14)
