SPY-BI-TAG: MSP430 SPY-BI-WIRE to TC2030-MCP Adapter Board

$29.50$31.00

TC2030‐MCP to SPY‐BI‐WIRE adapter board which allows use of our Tag‐Connect TC2030‐MCP series Plug‐of‐Nails™ cables with later versions of TI’s MSP430 MCU that support the SPY‐BI‐WIRE (2‐Wire) JTAG interface.

Clear
SKU: SPY-BI-TAG Categories: ,

Description

The “SPY‐BI‐TAG” TC2030‐MCP to SPY‐BI‐WIRE adapter board which allows use of our Tag‐Connect TC2030‐MCP series Plug‐of‐Nails™ cables with later versions of TI’s MSP430 MCU that support the SPY‐BI‐WIRE (2‐Wire) JTAG interface.

TI MSP‐FETU430 shown in one of the images with SPY‐BI‐TAG adapter board and TC2030‐MCP‐NL (no legs) cable – also works with TC2030‐MCP legged version cable. When your board real‐estate is at a premium, Tag‐Connect is the way to go!
The SPY-BI-TAG adapter can be fitted with the 330 Ohm fuse-blow protection resistor. The best (and safest) place for this resistor is on the adapter board, but some people (because they copy the confusing eval board schematics) put the 330 Ohm resistor on the target PCB. The resistor MUST be fitted either on the SPY-BI-TAG board, or on the target board but NOT both.

You can order this adapter with or without the 330 Ohm 0805 resistor fitted. Please select required option when ordering.

Note: Adapter only, MPS430, cable and evaluation board not included!

Datasheet

This product is used in the following debugger/device solutions:

This product is used as part of the following solutions for particular debuggers, protocols and devices. Solutions may involve additional cables, adapters or retaining clips, as well as this product you are viewing now. Click on the solution links to see full solutions and installation instructions where applicable.

TI MSP-FET430 for TI MSP430 using SPY-BI-WIRE
